reflective double bubble foil thermal insulation for building
| Place of Origin: | Shandong, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
This is a new environmentally-friendly heat insulation material, which can add a layer of PE woven cloth one the basis of the original aluminum foil
This is a new environmentally-friendly heat insulation material, which can add a layer of PE woven clothone the basis of the original aluminum foil and polyethyene, which greatly enhances tensile strength and tering-resistance strength without changing its original characterstics.
Technical parameters:
Material structure | AL + bubble + AL |
Bubble diameter and height | 2.5mm*10mm,4mm*10mm,7mm*20mm |
Size/roll | Normal size: 1.2m*40m. Max width is1.58m,length can be customized |
Reflectivity | 96%-97% |
Water Vapor Transmission | 0.013G/M2KPA |
Thermal conductivity | 0.034 |
Apparent density | 0.30KG/M2 |
Weight | 256G/M2 |
Tensile strength(MD) | 16.98Mpa |
Tensile strength(TD) | 16.5Mpa |
Corrosion | Doesn't generate |
Characteristics:
1.No odor and toxicity, environmentally- friendly;
2.Light, soft, dust free, fire retardant, easy to install;
3.Heat reflection, heat insulation, sound insulation, anti-radiation, anti-vibration, and shielding;
4.Moisture barrier, sun-proof, waterproof, good sealing property, heat preservation, energy saving…
5.Summer: moisture barrier, sun-proof, heat insulation, saving energy consumed by cool air conditioning ;
6.Winter: heat preservation, central heating saving, and remarkable energy-saving effect.
1.No odor and toxicity, environmentally- friendly;
2.Light, soft, dust free, fire retardant, easy to install;
3.Heat reflection, heat insulation, sound insulation, anti-radiation, anti-vibration, and shielding;
4.Moisture barrier, sun-proof, waterproof, good sealing property, heat preservation, energy saving…
5.Summer: moisture barrier, sun-proof, heat insulation, saving energy consumed by cool air conditioning ;
6.Winter: heat preservation, central heating saving, and remarkable energy-saving effect.
Application:
1.Used in Roof insulation
2.Used in Attic Insulation
3.Used in Stud Walls Insulation
4.Used in Crawl Spaces Insulation
5.Used in Under Concrete Barrier&Insulation
6.Used in HVAC Duct Insulation
7.Used in Metal Building Insulation
8.Used in Post Frame Building insulation
9.Used in Water Heater Insulation Blankets or Jackets.
10.Used in Radiant Floor Insulation
11.Used in Garage Door Insulation
12.Used in Ultra/Stanard Under Concrete Barrier
13.Used in Duct Wrap Insulation
Benefits:
Effective in extrme temperatures both hot and cold
Strong but clean ,light weight and flexible
Easy Installation
Safe to handle with no special clothing or breathing Equipment
Cuts and installs easier than fiberglass
Reflects 97% of Radiant Heat
Easily stapled, nailed or glued into place
Waterproof,non-absorbent surface,recycled ,friend environment.
